B25S-6
B25S-6
- September 12, 2016
0
Summary
- For street and racing use
- Maximum weight 900kg (2000lbs)
- Made from solid alloy billet
- Multi piston seals allow for low maintenance
- Hard satin black anodized
Recommended for
- Light racing cars
- Rally cars
- Street brake kit
Technical data
| Piston number | 6 |
| Rotor Ø (min-max) | 230-277mm (9-11″) |
| Rotor thickness (min-max) | 8-26mm |
| Rotor Depth | 45mm |
| Weight | 0.9kg (2lbs) |
| Mounting Type | Lug |
| Lug PCD | N/A |
| Anti knock-back Pistons | Optional |
| Mounting Centers | 141mm |
| Notes | |
| Piston Layout (Diameter in mm) | 26 / 31 / 26 |
| Total area (both sides) cm² | 363 |
| Pad Code | SP0153M |
| Pad Area cm² | 43 |
| Pad Choice | .113/.114/.116 |
| Pad Thickness | 15mm |
| Pad Depth | 45mm |
